SYBR SS695 Miniature Stainless Steel Ball Bearings Size Chart

> > >

SYBR SS695 Miniature Stainless Steel Ball Bearings Size Chart

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
needle roller bearing
CARB toroidal roller bearings
thrust roller bearings
Deep groove ball bearings
Angular contact ball bearings
Thrust ball bearings
Self-aligning ball bearing
Y-bearing
Description
Technical
Application
Pictures

The advantages of stainless steel ball bearing:

1.Excellent corrosion resistance

2.Can be washable

3.Can run in the liquid

4.Dried up relatively slowly

5.Health and non-corroding

6.High heat capacity



Application:

Medical device ,cryogenic engineering,optical instrument,high-speed machine,high-speed motor,printing machinery and food processing machinery and so on.



 Name

stainless steel deep groove ball bearing

 Material

stainless steel

 Type

Deep groove ball bearing

 Delivery

2-3 days for ex-stock

 Precision

International Standard

 Price

EXW price (factory wholesale price)

 Service

24 hours online

 Appication

Motor, Machinery, Electric Tools, Sports Apparatus, medical equipment, chemicals, aviation, perfume bottles, sprayers, valves, nail polish, body jewelry, mobile phone panels, toys, etc.

 Specialty

1) Very durable

2) High speed running
3) High quality

4) 2 years warranty

5) Good & competitive price



Other models of SS ball bearings:

Model                                           Overall Dimensions   Rated load Weight
kg
Inner Diameter
mm       inch
Outer Diameter
mm     inch
Width Rsmin
mm     inch
Cr N Cor N
Open
mm     inch
Close
mm     inch
SS695 5       0.1969 13     0.5118 4       0.1575 4       0.1575 0.2     0.008 1070 420 0.0023
SS696 6       0.2362 15     0.5906 5       0.1969 5       0.1969 0.2     0.008 1470 600 0.0036
SS697 7       0.2756 17     0.6693 5       0.1969 5       0.1969 0.3     0.012 1600 710 0.0050
SS698 8       0.3150 19     0.7480 6       0.2362 6       0.2362 0.3     0.012 2230 910 0.0076
SS699 9       0.3543 20     0.7874 6       0.2362 6       0.2362 0.3     0.012 2480 1090 0.0085
SS6900 10     0.3937 22     0.8661 6       0.2362 6       0.2362 0.3     0.012 2690 1270 0.0100
SS6901 12     0.4724 24     0.9449 6       0.2362 6       0.2362 0.3     0.012 2890 1460 0.0120
SS6902 15     0.5906 28     1.1024 7       0.2756 7       0.2756 0.3     0.012 4320 2250 0.0180
SS6903 17     0.6693 30     1.1811 7       0.2756 7       0.2756 0.3     0.012 4590 2550 0.0190
SS6904 20     0.7874 37     1.4567 9       0.3543 9       0.3543 0.3     0.012 6370 3680 0.0380
SS6905 25     0.9843 42     1.6535 9       0.3543 9       0.3543 0.3     0.012 6660 4180 0.0440
SS6906 30     1.1811 47     1.8504 9       0.3543 9       0.3543 0.3     0.012 7240 5010 0.0500
SS6907 35     1.3780 55     2.1654 10     0.3937 10     0.3937 0.6     0.024 10390 7160 0.0750
SS6908 40     1.5748 62     2.4409 12     0.4724 12     0.4724 0.6     0.024 13020 9200 0.1180
SS6909 45     1.7717 68     2.6772 12     0.4724 12     0.4724 0.6     0.024 13490 10130 0.1280
SS6910 50     1.9685 72     2.8346 12     0.4724 12     0.4724 0.6     0.024 13900 10990 0.1330
SS6911 55     2.1654 80     3.1496 13     0.5118 13     0.5118 1       0.039 14820 12690 0.1770
SS6912 60     2.3622 85     3.3465 13     0.5118 13     0.5118 1       0.039 15080 13480 0.1910
SS6913 65     2.5591 90     3.5433 13     0.5118 13     0.5118 1       0.039 19950 17490 0.2000
SS6914 70     2.7559 100     3.9370 16     0.6299 16     0.6299 1       0.039 25950 21850 0.3270
SS6915 75     2.9528 105     4.1339 16     0.6299 16     0.6299 1       0.039 26780 23560 0.3450
SS6916 80     3.1496 110     4.3307 16     0.6299 16     0.6299 1       0.039 27590 25280 0.3630
SS6917 85     3.3465 120     4.7244 18     0.7087 18     0.7087 1.1     0.043 31900 29700 0.5170

SYBR Miniature Stainless Steel Ball Bearings Catalog:


application

SYBR SS695 Miniature Stainless Steel Ball Bearings Pictures:
