NTN 6210LLU/2ASU1 Deep Groove Ball Bearing 6210ZZCM 6210

> > >

NTN 6210LLU/2ASU1 Deep Groove Ball Bearing 6210ZZCM 6210

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
needle roller bearing
CARB toroidal roller bearings
thrust roller bearings
Deep groove ball bearings
Angular contact ball bearings
Thrust ball bearings
Self-aligning ball bearing
Y-bearing
Description
Technical
Application
Pictures
NTN 6210LLU/2ASU1 Deep Groove Ball Bearing 6210ZZCM 6210

NTN 6210LLU/2ASU1 bearing are machined components that include an outer ring, inner ring, balls, retainers, shields and snap rings. miniature ball bearings are available in inch and metric sizes, open or shielded and flanged or unflanged. For extreme noise sensitive applications, superior hardness and corrosion resistance our ball bearings are manufactured with DD400™ stainless steel material.  Single-row deep groove ball bearings are the most common type of rolling bearings. Their use is very widespread.
In addition to open type bearings, these bearings often have steel shields or rubber seals installed on one or both sides and are prelubricated with grease. Also, snap rings are sometimes used on the periphery. As to cages, pressed steel ones are the most common.

NTN 6205LLU/2ASU1 Deep Groove Radial Ball Bearing 6205LLU C3


Bearing number : 6210LLU

Size (mm) : 50x90x20

Brand : NTN

Bore Diameter (mm) : 50

Outer Diameter (mm) : 90

Width (mm) : 20

Bearing dimensions and specification in brand catalogue :

d - 50 mm

D - 90 mm

B - 20 mm

C - 20 mm

r min. - 1,1 mm

da min. - 56,5 mm

da max - 60 mm

Da max. - 83,5 mm

ra max. - 1 mm

Weight - 0,454 Kg

Basic dynamic load rating (C) - 35 kN

Basic static load rating (C0) - 23,2 kN

Reference speed - 4 700 r/min

Calculation factor (f0) - 14,4

Model d/mm D/mm B/mm Weight/KG
6000LLU/ZZ 10 26 8 0.042
6001LLU/ZZ 12 28 8 0.049
6002LLU/ZZ 15 32 9 0.066
6003LLU/ZZ 17 35 10 0.086
6004LLU/ZZ 20 42 12 0.152
6005LLU/ZZ 25 47 12 0.216
6006LLU/ZZ 30 55 13 0.256
6007LLU/ZZ 35 62 14 0.342
6008LLU/ZZ 40 68 15 0.423
6009LLU/ZZ 45 75 16 0.54
6010LLU/ZZ 50 80 16 0.575
6200LLU/ZZ 10 30 9 0.071
6201LLU/ZZ 12 32 10 0.082
6202LLU/ZZ 15 35 11 0.099
6203LLU/ZZ 17 40 12 0.143
6204LLU/ZZ 20 47 14 0.234
6205LLU/ZZ 25 52 15 0.282
6206LLU/ZZ 30 62 16 0.439
6207LLU/ZZ 35 72 17 0.635
6208LLU/ZZ 40 80 18 0.807
6209LLU/ZZ 45 85 19 0.897
6210LLU/ZZ 50 90 20 1.02
6300LLU/ZZ 10 35 11 0.117
6301LLU/ZZ 12 37 12 0.132
6302LLU/ZZ 15 42 13 0.181
6303LLU/ZZ 17 47 14 0.254
6304LLU/ZZ 20 52 15 0.317
6305LLU/ZZ 25 62 17 0.511
6306LLU/ZZ 30 72 19 0.763
6307LLU/ZZ 35 80 21 1.01
6308LLU/ZZ 40 90 23 1.4
6309LLU/ZZ 45 100 25 1.84
6310LLU/ZZ 50 110 27 2.36

Widely used in metallurgy ,mining ,petroleum,chemical,coal,cement ,paper,windpower,heavy machinery ,enginnering machinery,port machinery and other industries.
