NTN NA5901 Needle Roller Bearings

> > >

NTN NA5901 Needle Roller Bearings

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
needle roller bearing
CARB toroidal roller bearings
thrust roller bearings
Deep groove ball bearings
Angular contact ball bearings
Thrust ball bearings
Self-aligning ball bearing
Y-bearing
Description
Technical
Application
Pictures
NTN needle bearing NA5901 Description:

Needle roller bearings are essentially cylindrical roller bearings except that their cylindrical rollers have a length 3 to 10 times their diameter (versus less a length less than 3 times their diameter). Therefore, the ratio of the bearing outside diameter to the inscribed circle diameter is small, and they have a rather high radial load capacity.

Even though they have a low cross section, precision needle roller bearings have a high radial load capacity and are exceptionally suited for bearing applications where radial space is limited.


 Name

 NTN needle bearing NA5901

 Sizes

 12*24*16 mm

 Material

 Chrome steel Gcr15

 Delivery

 2-3 days

 Price

 EXW price (factory wholesale price)

 Service

 24 hours online

 Appication

Motor, Machinery, Electric Tools, Sports Apparatus, medical equipment, chemicals, aviation, perfume bottles, sprayers, valves, nail polish, body jewelry, mobile phone panels, toys, etc.

 Specialty

 needle bearing NAS5010:

 1) Very durable

 2) High speed running
 3) High quality

 4) 2 years warranty

 5) Good & competitive price


NTN needle bearing NA5901 Size Chart:


NO. NO. SIZE
WITH INNER WITHOUT INNER mm
d Fw D C r min
NA5902 RNA5902 15 20 28 18 0.3
NA5903 RNA5903 17 22 30 18 0.3
NA5904 RNA5904 20 25 37 23 0.3
NA59/22 RNA59/22 22 28 39 23 0.3
NA5905 RNA5905 25 30 42 23 0.3
NA59/28 RNA59/28 28 32 45 23 0.3
NA5906 RNA5906 30 35 47 23 0.3
NA59/32 RNA59/32 32 40 52 27 0.6
NA5907 RNA5907 35 42 55 27 0.6
NA5908 RNA5908 40 48 62 30 0.6
NA5909 RNA5909 45 52 68 30 0.6
NA5910 RNA5910 50 58 72 30 0.6
NA5911 RNA5911 55 63 80 34 1
NA5912 RNA5912 60 68 85 34 1
NA5913 RNA5913 65 72 90 34 1
NA5914 RNA5914 70 80 100 40 1
NA5915 RNA5915 75 85 105 40 1
NA5916 RNA5916 80 90 110 40 1
NA5917 RNA5917 85 100 120 46 1.1
NA5918 RNA5918 90 105 125 46 1.1
NA5919 RNA5919 95 110 130 46 1.1
NA5920 RNA5920 100 115 140 54 1.1
NA5922 RNA5922 110 125 150 54 1.1
NA5924 RNA5924 120 135 165 60 1.1
NA5926 RNA5926 130 150 180 67 1.5
NA5928 RNA5928 140 160 190 67 1.5

NTN NA5901 needle roller bearings application:

Needle roller bearings NA5901 application:

- Needle roller bearings are largely suitable for automotive transmissions

- air-conditioner compressors

- bulldozer blades

- overhead traveling cranes

- gearboxes

- machine tool spindles

- copying machines and many more

split needle bearings.jpg

NTN NA5901 needle roller bearing photos:



split needle bearings.jpg


split needle bearings
