Different types of bearing housings
1)Pillow blocks – these include UCP, HCP, UCLP, UKP, UCPX, and UKPX.
These mounted bearings are used when support for a rotating shaft axis is required. Their design enables them to support the shaft in operations where the mounting surface is parallel to the shaft axis.
2)Flange type– includes UCF, HCF, UKF, UCFX, UKFX, UCFU, UCFC, UKFC, UCFS, UCFL, UKFL, UCFT.
The flange type bearing housing comes in various shapes and styles such as square, round, and rhombus flange types.
3)Take-up units type - UCT, HCT, and UKT.
These bearing housings have an inner surface which is concave sphered hence the bearing used has a convex sphered outer surface. They are designed to permit moderate initial misplacement. Widely used in conveyor chains and conveyor belts. A sliding slot at the side of the housing facilitates the free movement of the unit.
4)Cartridge type – UCC, HCC, and UKC.
This type of bearing housing has a cylindrical outer perimeter hence the bearing outer bore is spherical. The entire unit allows free movement in the axial direction and is self-aligning. This type can be used as free side bearings for long shafts because they are capable of accommodating shaft expansion or contraction due to temperature differences. Also suitable where there is adjustment of the axial direction is required.
5)Light duty types SAFD, SBFD, SAFW, SBFW, SALF, and SBLF.
Application of the pillow block bearings
1.Economical housed bearing solution
2.Light and heavy industrial use Pillow Block Bearing
3.Agricultural and Automotive Pillow Block Bearing
4.Conveyor and Fan assemblies Pillow Block Bearing
5.Fabricated machine assembly Pillow Block Bearing
6.Great value quality parts dispatched the same day
Bearing | Pillow block bearings |
Brand Name | NSK NTN KOYO SYBR OEM ASAHI |
Bore Size | 1-100(mm) |
Outside Diameter | 2-150(mm) |
width | 1-50(mm) |
Material | Ring Material Chrome Steel ,Carbon steel,Stainless steel |
Clearance | C0,C2,C3,C4,C5 |
Vibration | Zv1,Zv2 and Zv3 |
Precision Rating | P0,P6,P5 |
Greese | As you requirement, such as SRL ,PS2, Alvania R12 and so on |
Number of Row | Single Row |
Guarantee | 1 year |
Application | Home appliances, low noise and high speed electric motors, |
automotivecomponents, pumps, machinery. | |
Certifications | ISO 9001:2008, SASO,CE |
Package | Single box or according to buyers requirement . |
Place of Origin | China (Mainland) |
MOQ | 1 PCS |
Payment Term | T/T or L/C or West Union |
Unit No. |
Dimensions mm |
Housing No. |
Weight |
|||||||||||
d |
h |
a |
e |
b |
s1 |
s2 |
g |
w |
t |
B |
n |
(kg) |
||
UCP201 |
12 |
30.2 |
127 |
95 |
38 |
13 |
19 |
14 |
62 |
44.5 |
31 |
12.7 |
P203 |
0.69 |
UCP202 |
15 |
30.2 |
127 |
95 |
38 |
13 |
19 |
14 |
62 |
44.5 |
31 |
12.7 |
P203 |
0.69 |
UCP203 |
17 |
30.2 |
127 |
95 |
38 |
13 |
19 |
14 |
62 |
44.5 |
31 |
12.7 |
P203 |
0.68 |
UCP204 |
20 |
33.3 |
127 |
95 |
38 |
13 |
19 |
15 |
71 |
48 |
34.1 |
14.3 |
P204 |
0.66 |
UCP205 |
25 |
36.5 |
140 |
105 |
38 |
13 |
19 |
15 |
71 |
48 |
34.1 |
14.3 |
P205 |
0.81 |
UCP206 |
30 |
42.9 |
165 |
121 |
48 |
17 |
20 |
17 |
84 |
53 |
38.1 |
15.9 |
P206 |
1.24 |
UCP207 |
35 |
47.6 |
167 |
127 |
48 |
17 |
20 |
18 |
93 |
59.5 |
42.9 |
17.5 |
P207 |
1.58 |
UCP208 |
40 |
49.2 |
184 |
137 |
54 |
17 |
20 |
18 |
100 |
69 |
49.2 |
19 |
P208 |
1.89 |
UCP209 |
45 |
54 |
190 |
146 |
54 |
17 |
20 |
20 |
106 |
69 |
49.2 |
19 |
P209 |
2.14 |
UCP210 |
50 |
57.2 |
200 |
159 |
60 |
20 |
23 |
21 |
113 |
74.5 |
51.6 |
19 |
P210 |
2.66 |
UCP211 |
55 |
63.5 |
219 |
171 |
60 |
20 |
23 |
23 |
125 |
76 |
55.6 |
22.2 |
P211 |
3.31 |
UCP212 |
60 |
69.8 |
241 |
184 |
70 |
20 |
23 |
25 |
138 |
89 |
65.1 |
25.4 |
P212 |
4.9 |
UCP213 |
65 |
76.2 |
265 |
203 |
70 |
25 |
28 |
27 |
150 |
89 |
65.1 |
25.4 |
P213 |
5.15 |
UCP214 |
70 |
79.4 |
266 |
210 |
72 |
25 |
28 |
27 |
156 |
|
74.6 |
30.2 |
P214 |
6.2 |
UCP215 |
75 |
82.6 |
275 |
217 |
74 |
25 |
28 |
28 |
162 |
|
77.8 |
33.3 |
P215 |
7.16 |
UCP216 |
80 |
88.9 |
292 |
232 |
78 |
25 |
28 |
30 |
174 |
|
82.6 |
33.3 |
P216 |
8.1 |
UCP217 |
85 |
95.2 |
310 |
247 |
83 |
25 |
28 |
32 |
185 |
|
85.7 |
34.1 |
P217 |
9.81 |
UCP218 |
90 |
101.6 |
327 |
262 |
88 |
27 |
30 |
33 |
198 |
|
96 |
39.7 |
P218 |
11.96 |
