SYBR 7205BEP BECBP nylon cage angular contact ball bearing wholesale ball bearings

> > >

SYBR 7205BEP BECBP nylon cage angular contact ball bearing wholesale ball bearings

Our company can provide specific bearing parameter, drawings, one-to-one solutions, and considerate after sales service. For more product information, please consult us at any time .We provide 24-hour service and await your calls respectfully!
needle roller bearing
CARB toroidal roller bearings
thrust roller bearings
Deep groove ball bearings
Angular contact ball bearings
Thrust ball bearings
Self-aligning ball bearing
Y-bearing
Description
Technical
Application
Pictures
SYBR 7205BEP BECBP nylon cage angular contact ball bearing wholesale ball bearings

Wholesale ball bearing angular contact ball bearings in a tandem arrangement are used when the actual thrust force exceeds the thrust load capacity of a single angular contact ball bearing , Single row angular contact ball bearings in tandem arrangement must always be adjusted against another bearing inversely arranged for shaft guidance in the opposite direction , angular contact ball bearings in spindle bearing design must not be exposed to any misalignments .

QQ20150529110752

Bearing name 7205BECBP bearing
New model 7205BECBP
Old model bearing
Products types 7205BECBP Angular Contact Ball Bearings
Categories Angular Contact Ball Bearings
Brands SHR
Dimensions (mm)
Inside diameter ID d 25
Outside diameter OD D 52
Thickness B 15
Size (IDxODxB)mm 25*52*15 mm
Weight /kg 0.13

SYBR 7205BEP BECBP nylon cage angular contact ball bearing wholesale ball bearings models series

designation Dimensions
d (mm) D (mm) B (mm)
7200 BECBP 10 30 9
7201 BECBP 12 32 10
7202 BECBP 15 35 11
7202 BECBP 15 35 11
7203 BECBP 17 40 12
7303 BECBP 17 47 14
7204 BECBP 20 47 14
7304 BECBP 20 52 15
7302 BECBP 15 42 13
7204 BECBP 20 47 14
7304 BECBP 20 52 15
7205 BECBP 25 52 15
7305 BECBP 25 62 17
7206 BECBP 30 62 16
7206 BEGBP 30 62 16
7207 BECBP 35 72 17
7307 BECBP 35 80 21
7208 BECBP 40 80 18
7308 BECBP 40 90 23
7209 BECBP 45 85 19
7309 BECBP 45 100 25
7210 BECBP 20 90 50
7215 BECBP 75 130 25
7315 BECBP 75 160 37
7216 BECBP 80 140 26
7316 BECBP 80 170 39
7217 BECBP 85 150 28
7317 BECBP 85 180 41
7218 BECBP 90 160 30
7318 BECBP 90 190 43
7219 BECBP 95 170 32
7319 BECBP 95 200 45
7220 BECBP 100 180 34
7306 BECBP 30 72 19
7310 BECBP 27 110 50
7211 BECBP 21 100 55
7311 BECBP 55 120 29
7212 BECBP 60 110 22
7312 BECBP 60 130 31
7213 BECBP 65 120 23
7313 BECBP 65 140 33
7214 BECBP 70 125 24
7314 BECBP 70 150 35
7320 BECBP 100 215 47
7221 BECBP 105 190 36
7321 BECBP 105 225 49
7222 BECBP 110 200 38
7322 BECBP 110 250 50



7210 BECBY

7211 BEP

7212 BECBY

AMS 20 ABP

7210 BEGAP *

7211 BEY

7212 BEGAM *

7213 BECBJ

7210 BEP

7311 BECBJ

7212 BEGAP *

7213 BECBM

7210 BEY

7311 BECBM *

7212 BEGBP *

7213 BECBP

7310 BECBJ

7311 BECBP *

7212 BEP

7213 BECBY

7310 BECBM *

7311 BECBPH *

7212 BEY

7213 BEGAF

7310 BECBP *

7311 BECBY

7312 BECAP *

7213 BEGAP

7310 BECBY

7311 BECCM *

7312 BECBJ

7213 BEGAY

7310 BEGAF

7311 BEGAM *

7312 BECBM *

7213 BEP

7310 BEGAM *

7311 BEGAP *

7312 BECBP *

7213 BEY

7310 BEGAP *

7311 BEGAY

7312 BECBPH *

7313 BECBF

7310 BEGAY

7311 BEGBM *

7312 BECBY

7313 BECBJ

7310 BEGBP *

7311 BEGBY

7312 BECCM *

7313 BECBM *

7310 BEGBY

7311 BEGCY

7312 BEGAM *

7313 BECBP *

7310 BEP

7311 BEP

7312 BEGAP *

7313 BECBPH *

7310 BEY

7311 BEY

7312 BEGAY

7313 BECBY

7410 BCBM

7411 BCBM

7312 BEGBM *

7313 BECCM *

7410 BM

7411 BGAM

7312 BEGBP *

7313 BEGAF

AMS 16 ABP

7411 BGBM

7312 BEGBY

7313 BEGAM *

7211 BECBJ

7411 BGM

7312 BEM

7313 BEGAP *

7211 BECBM *

7411 BM

7312 BEP

7313 BEGBM *

7211 BECBP *

AMS 18 ABP

7312 BEY

7313 BEGBP *

7211 BECBY

7212 BECBJ

7412 BCBM

7313 BEGBY

7211 BEGAP *

7212 BECBM *

7412 BGAM

7313 BEP

7211 BEGBY

7212 BECBP *

7412 BM

7413 BCBM



SYBR 7205BEP BECBP nylon cage angular contact ball bearing wholesale ball bearings application :


Single row: machine tool spindle,  high frequency motor, gas turbine, centrifuge, differential pinion-shaft, small cars’s front wheel, etc.

Double row: oil pump, roots blower, air compressor, all kinds of transmission gearbox, fuel injection pump, printing machinery, etc.


SYBR 7205BEP BECBP nylon cage angular contact ball bearing wholesale ball bearings photos :




Bearing other series product range:
1. Deep Groove Ball Bearings (Single) 1600, 623, 607, 6000
2. Deep Groove Ball Bearings (Single) 6200 Series
3. Deep Groove Ball Bearings (Single) 6300, 6400 Series
4. Angular Contact Ball Bearings (Duplex) 3200, 3300, 5200, 5300 Series
5. Deep Groove Ball Bearings (Double) 4200, 4300
6. Angular Contact Ball Bearings (Single) 7200, 7300 Series
7. Self Aligning Ball Bearings 1200, 1300, 2200, 2300 Series
8. Spherical Roller Bearings 21300, 22200 Series
9. Spherical Roller Bearings 22300, 23200 Series
10. Trust Ball Bearings 5110, 51200 Series
11. Taper Roller Bearings 302 Series
12. Taper Roller Bearings 303 Series
13. Taper Roller Bearings 313 Series
14. Taper Roller Bearings 320 Series
15. Taper Roller Bearings 322 Series
16. Taper Roller Bearings 323 Series
17. Taper Roller Bearings (Imperial Sizes Supplied Separately)
18. Pillow Blocks (Normal Duty) UCP 200 Series
19. Pillow Blocks (Medium Duty) UCP X00 Series
20. Flange Units (Normal Duty) UCF 200 Series
21. Flange Units (Medium Duty) UCF X00 Series
22. Flange Units (Normal Duty) UCFL 200 Series
23. Pillow Blocks (Light Duty Pressed Steel Housing) SBP - SAP Series
24. Flange Units (Light Duty Pressed Steel Housing) SBFL, SAFL Series
25. Flange Units (Light Duty Pressed Steel Housing) SBF - SAF Series
26. Ball Bearings UC200, CUC 200 Series
27. Ball Bearings (With Eccentric Locking Collar) SA200, CSA200 Series
28. Ball Bearings SB200, CSB200 Series
29. Disc Harrow Bearings W 200 Series
30. Ball Bearings Units (Load Rating Data)
31. Take-up Units (Normal Duty) UCT 200, UCST 200 Series
32. Plumber Blocks SN/SSN500, SN/SSN600 Series
33. Plumber Blocks (Sealing Arrangements)
34. Plumber Blocks (Application References)
35. Plumber Blocks SNU 500 - 600 Series
36. Plumber Blocks SD3100 Series
37. Plumber Blocks (Application References)
38. Adaptor Sleeves H2 & H3 Series
39. Adaptor Sleeves H23 Series
40. Adaptor Sleeves H31 & H32 Series
