SYBR 5307 2RS angular type double row ball bearing


Angular contact bearings are able to support radial load and axial load. As single row angular contact ball bearings can only support axial load in single direction, matched bearing mounting is often adopted to them as matched parts of bearings, preload for them is more convenient.



Contact angles: C-15°, A5-25°, A-30°, B-40°



Cage materials: brass, synthetic resin, molded polyamide resin.



Double row angular contact ball bearing can bear the large radial and axial combined load, and its limit speed is high.It is the non-separated type of bearing.Compared with the single row angular contact ball bearing, it has thgh rigidity, and it can bear the two-way axial load.





        Nylon cage ball bearing 5307 ZZ rodamientos 5307 2RS S5307







Nylon cage ball bearing 5307 2RS rodamientos 5307 2RS S5307 design and datas :

Nylon cage ball bearing 5307 ZZ rodamientos 5307 2RS S5307

SYBR 5307 2RS angular type double row ball bearing MODELS REFERENCE :


Basic Bearing  No. Main Dimension(mm) Load rating / KN maximum   speed Weight
d                        D                B             r              Dynamic           C Static             C0 Grease       r/min Oil              r/min approximate
KG
5302 15 42 19.0 1.0 12.8 7.9 10000 15000 0.132
5303 17 47 22.2 1.0 20.4 12.1 8000 12000 0.181
5304 20 52 22.2 1.0 20.6 12.7 8000 12000 0.227
5305 25 62 25.4 1.1 30.5 20.5 7500 10000 0.362
5306 30 72 30.2 1.1 39.5 27.5 6500 8000 0.553
5307 35 80 34.9 1.5 49.5 35.0 5300 7000 0.766
5308 40 90 36.5 1.5 60.5 44.0 5000 6500 1.010
5309 45 100 39.7 1.5 72.5 54.0 4300 5600 1.340
5310 50 110 44.4 2.0 85.5 64.5 4000 5300 1.810
5311 55 120 49.2 2.0 106.0 82.0 3600 4800 2.320
5312 60 130 54.0 2.1 122.0 95.5 3500 4500 3.050
5313 65 140 58.7 2.1 138.0 109.0 3000 4000 3.960
5314 70 150 63.5 2.1 155.0 125.0 2800 3800 4.740
5315 75 160 68.3 2.1 168.0 141.0 2600 3200 5.650
5316 80 170 68.3 2.1 175.0 151.0 2200 3000 7.210
5317 85 180 73.0 3.0 195.0 176.0 2000 3000 8.300
5318 90 190 73.0 3.0 225.0 266.0 2000




SYBR 5307 2RS angular type double row ball bearing application :

1.Single row angular contact ball bearings: machine tool spindles, high frequency motors, gas turbines, centrifuges, small car front wheel, differential pinion shaft

2.Double row angular contact ball bearings: pump, blower, air compressor, various types of transmission, fuel injection pumps, printing machinery




PACKING :
1.Carton (up to 150mm of ID);
2.Wrapped by oil paper and water-proof belt ( above 150mm of ID);
3.Wooden pallets or wooden cases of free fumigation
4.or According to customer's requirement





SYBR 5307 2RS angular type double row ball bearing photos series :
